ICON 6-8″ Lift Front Shocks V.S. 2.5 Series Piggyback Reservoir for 2011-2017 Chevy/GMC 2500HD

ICON 6-8" Lift Front Shocks V.S. 2.5 Series Piggyback Reservoir for 2011-2017 Chevy/GMC 2500HD
ICON 6-8" Lift Front Shocks V.S. 2.5 Series Piggyback Reservoir for 2011-2017 Chevy/GMC 2500HD

Description
ICON 6-8″ Lift Front Shocks V.S. 2.5 Series Piggyback Reservoir for 2011-2017 Chevy/GMC 2500HD

ICON 6-8″ Lift Front Shocks V.S. 2.5 Series Piggyback Reservoir for 2011, 2012, 2013, 2014, 2015, 2016, 2017 Chevy/GMC 2500HD

Part: 77736P

OVERVIEW:

ICON Vehicle Specific (V.S.) 2.5 Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications; ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. If you are looking for a more user defined tune, consider looking into the Compression Damping Control Valve (CDCV) or the OMEGA Series bypass shocks.

KEY FEATURES:

  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with piggyback reservoir
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 7/8” diameter induction hardened, chrome plated shock shaft
  • PTFE lined spherical bearings and application specific mounting hardware
  • 6061 aircraft grade aluminum CNC machined components
  • CAD plated, precision machined 1026 DOM steel shock body for maximum durability and corrosion resistance
  • 100% Rebuildable
  • 100% Revalveable
  • Made in the U.S.A.
  • All ICON 2.5 Series Piggyback and Remote Reservoir shocks can be upgraded to ICON’s Compression Damping Control Valve (CDCV)

NOTES:

  • ICON V.S. 2.5 Series shocks are sold in pairs
  • Price listed is for two (2) shock absorbers
  • For individual shock purchase, please contact an authorized ICON dealer

Additional information

Weight 59 lbs
Dimensions 28 × 8 × 8 in
