ICON 4.5″ Lift Kit Stage 3 for 2003-2008 Dodge Ram 2500/3500 4WD
$4,732.73
Description
ICON Stage 3 4.5 inches Lift Suspension System for 2003–2008 Ram 2500/3500 4WD
Part Number: K214502T
Summary: The ICON Stage 3 suspension system provides a 4.5-inch lift height for the 2003–2008 Ram 2500/3500 4WD, specifically engineered to increase ground clearance while maintaining proper steering geometry. This mid-level performance system upgrades the vehicle with 2.5 Series Aluminum shocks and heavy-duty fixed tubular link arms to reduce bushing bind and improve alignment range. It is designed as a comprehensive solution for diesel-equipped Rams used for towing, construction site navigation, and off-road excursions without sacrificing highway ride quality.
Features
- 2.5 Aluminum Series Shocks: 2.5-inch diameter bodies with 7/8-inch shafts provide increased oil volume and consistent damping to ensure fade-free performance during aggressive use.
- Dual Rate Coil Springs: Diesel-specific dual rate springs provide a soft initial rate for street comfort and a firmer secondary rate to ensure superior bottom-out resistance.
- Fixed Tubular Links: Heavy-duty steel upper and lower link bars provide increased strength and improved alignment geometry to ensure reduced bind compared to factory bushings.
- Optimized Steering: Correctly positioned steering and track bar components provide stable handling to ensure minimal body roll and no change in towing capacity.
- System Durability: Billet top caps, rod ends, and FK bearings provide premium construction to ensure long-term reliability in harsh environments.
- Installation: A direct-fit design provides a straightforward upgrade path to ensure no drive shaft modifications are required for the 4.5-inch lift height.
Technical Specifications
| Specification | Value |
|---|---|
| Stage | Stage 3 |
| Front Lift Range | 4.5 inches |
| Shock Series | 2.5 Series Remote Reservoir Front / Piggyback Rear |
| UCA Type | Fixed Tubular Steel Links (Upper & Lower) |
| Rear Spring Type | 2.5 inches Lift Block Kit |
Wheel & Tire Fitment
- OEM Wheels & Tires: Yes
- Aftermarket Wheels: 17×8.5 inches w/ 5.25” BS, 18×9 inches w/ 5.50 inches BS, or 20×9 inches w/ 5.50 inches BS
- Aftermarket Tires: 35 inches x 12.50 inches (Larger tires may fit but fender trimming and modifications will be required)
- Note: Trucks equipped with 03-06 style steering will require 4 inches drop pitman arm (Not Included) or upgrade to 07-12 steering setup. Trucks equipped with 07-12 style steering will need ICON Pitman Arm Part# 214101.
System Components
- 214010 | 03-12 RAM HD 4WD 4.5 inches DUAL RATE SPRING KIT
- 214040 | 03-12 RAM HD 4.5 inches BOX KIT
- 214027 | 03-12 RAM HD FIXED TUBULAR LINK KIT
- 211205 | 03-12 RAM HD 4WD 2.5 inches BLOCK KIT
- 37023 | 99-10 FSD DUALLY/03-12 RAM HD 15 inches U-BOLT KIT
- 217810P | 03-12 RAM HD 4.5 inches FRONT 2.5 VS RR PAIR
- 217701P | 03-12 RAM HD 2-3\” REAR 2.5 VS PB PAIR
Why Choose ICON Stage 3?
- Performance Engineering: Increased wheel travel and damping for superior control.
- Heavy-Duty Links: Steel link arms increase strength and range of alignment over factory components.
- Fully Serviceable: Shocks are rebuildable and revalveable for long-term performance.
Frequently Asked Questions
Will this kit affect my towing capacity?
No
