ICON 2.5-3″ Lift Kit Stage 2 for 2016-2023 Nissan Titan XD

Description
ICON 2.5-3″ Lift Kit Stage 2 for 2016-2023 Nissan Titan XD

ICON 2.5-3″ Lift Kit Stage 2 for 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Nissan Titan XD

Part: K83032

OVERVIEW:

The 2016 Nissan Titan XD is an all new truck with a heavy-duty build that’s aimed to blend the lines between ½ ton efficiency and ¾ ton capability. With this in mind, ICON Vehicle Dynamics has developed a complete suspension system designed from the ground up for improved performance on and off-road, increased wheel travel over stock, and the best ride quality on the market. The Stage 2 system includes ICON 2.5 Series remote reservoir coilovers , 2.5 Series rear shocks, Delta Joint upper control arms, rear lift blocks, and u-bolts . These products feature high-quality components such as ICON-designed coil springs, precision machined internals, FK Rod End bearings, and a vehicle-specific shock tune that translates to a ride quality that is second to none. The ICON Vehicle Dynamics 2016-UP Nissan Titan XD Stage 2 suspension system is an excellent choice for drivers looking to drastically enhance the capabilities of their pickup on and off-road.

This system features upper control arms with ICON’s patent pending Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

KEY FEATURES:

• Fits 2WD / 4WD applications
• Increased ride quality over stock with no change in towing capacity
• Approximately 32% increased front wheel travel over stock
• Adjustable coilovers provide 2.5-3″ of lift height
• Vehicle specific tuned front and rear shocks for superior shock damping and control
• 6061 aircraft grade aluminum CNC machined components
• Corrosion resistant CAD plated shock body with 7/8″ shaft (2.5 Series shocks)
• FK Rod End bearings for extended longevity and minimal deflection
• 100% bolt-on system

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 5″ Backspace

Aftermarket Tires: 33 x 11.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)

SYSTEM COMPONENTS:

81521 (QTY.1) | 16-UP TITAN XD 2.5 RR CO KIT

88510DJ (QTY.1) | 16-UP TITAN XD DELTA JOINT UCA KIT

87705P (QTY.1) | 16-UP TITAN XD 0-1.5″ 2.5 VS PB PAIR

88700 (QTY.1) | 16-UP TITAN XD 9″ U-BOLT KIT

191201 (QTY.1) | 1″ CAST BLOCK KIT

OPTIONS:

191011 | Cover Cap for Tubular UCA
198000 | Spanner Wrench
614500 | Uniball Service Kit
